英伟达Jetson Orin NX/Orin Nano AI一体摄像机-PHX-N1000
PHX-1000系列特点：
• 灵活的模块化AI摄像头
• 兼容nVidia Jetson Orin Nano/Orin NX
• 镜头采用磁吸方式，可依场景需求灵活选择
• 多个I/O接口连接
• 宽工作温度范围-20˚C至70˚C
| 卷帘快门摄像机规格 | ||
|---|---|---|
| Image Sensor | SONY IMX335 | SONY IMX415 |
| Pickup Device / Shutter | 1/2.8", Rolling shutter | 1/2.8", Rolling shutter |
| Resolution | 5MP (2560x1920), CMOS | 8MP/4K (3840x2160), CMOS |
| Lens | 3.16mm, Fixed Lens, F1.8 | 1.74mm, Fixed Lens, F1.8 |
| Angle of View (H, V, D) | 97.0°, 73.0°, 126.0° | 125.4.°, 67°, 148.4° |
| Lens Type | Build | Build |
| Shutter | Rolling | Rolling |
| Pixel Size | 2.0um x 2.0um | 1.45um x 1.45um |
| Frame rate (max.) | 30fps | 30fps |
| Color/Mono | Color | Color |
| Wide Dynamic Range | HDR(2T) | WDR(1T) |
| 全局快门摄像机规格 | ||
|---|---|---|
| Image Sensor | ONSEMI AR0234 | ONSEMI AR0234 |
| Pickup Device / Shutter | 1/2.6", Global shutter | 1/2.6", Global shutter |
| Resolution | 2.3M(1920x1200), CMOS | 2.3M(1920x1200), CMOS |
| Lens | 3.48mm, Fixed Lens, F1.8 | 6mm-22mm, Zoom Lens |
| Angle of View (H, V, D) | 113.4°, 95.8°, 59.6° | W:55.4°, 43.4°, 32.0° T:21.6°, 17.4°, 13.1° |
| Lens Type | Build | Build |
| Shutter | Global | Global |
| Pixel Size | 3.0um x 3.0um | 3.0um x 3.0um |
| Frame rate (max.) | 100fps | 100fps |
| Color/Mono | Color | Color |
| Wide Dynamic Range | WDR(1T) | WDR(1T) |
| AI主机规格 | |
|---|---|
| 核心模组 | 兼容NVIDIA Jetson Orin™ NX/Orin™ Nano |
| 存储 | 1x M.2 M-Key slot support NVMe 1x Micro SD Card Slot |
| Ethernet | 1x GbE with 802.3 bt PoE PD, RJ45 |
| Series | 1x RS-485, Terminal Block |
| Digital I/O | 2x Alarm Input, Terminal Block 2x Alarm Output, Terminal Block |
| Display | 1x HDMI 2.0- Output |
| Audio | 1x Mic-in、1x Line-out |
| SD Card | 1x Micro SD Card Slot |
| USB | 1x USB 2.0 Type-C、1x USB Type-C for Config |
| Power Input | 1x 12VDC Power-input, Terminal Block |
| Power Button | 1x Reset button |
| LED | 1x dual-color LED (Power by DC, Power by PoE) |
| Expansion | 1x M.2 E-key 2230 |
| OS | Ubuntu: 22.04（JetPack 6.0 or Higher） |
| Power Requirements | PoE (IEEE 802.3bt)/DC 12V |
| Dimensions (W x D x H) | 100mm x 217.7mm x 88mm |
| Weight | 1.6 kg |
| Mounting/Installation | 1/4-20 UNC Screw holes |
| Operating temp. | -20~70°C with Airflow |
| Storage Temp. | -40~80°C |
| Storage Humidity. | 5% ~ 95%, non-condensing |
| Regulation | CE, FCC |
